Super Centurion®

Super Centurion®
Performance and longevity are the real tests of a fire hydrant. Superior flow characteristics, easy operation and maintenance, and life-extending features are among the benefits of installing a Mueller® Super Centurion fire hydrant. Super Centurion hydrants are made in our U.S.A. plant that is ISO 9001 certified, and backed by a 10-year limited warranty on materials and workmanship.
Features include:
- 10-year limited warranty on material and workmanship
- Meets all applicable parts of ANSI/AWWA C502 Standard
- Post type dry barrel design
- Dry top design with O-ring sealed oil reservoir
- Traffic feature with stainless steel safety stem coupling
- Compression-type main valve closes with pressure for positive seal; it is made of rubber and is conveniently reversible providing a spare for long service life
- Operating nut available in wide variety of shapes and sizes - open left or right
- Field replaceable hose and pumper nozzles
- Hose and pumper nozzles have large radius, full-flow openings for low friction loss
- Contoured shoe is designed for full flow
- Dual bronze drain valves provide effective barrel drainage
- 350 psig (2400 kPa/24 barg) maximum working pressure, 700 psig (4800 kPa/48 barg) static test pressure
- 250 psig (1725 kPa/17 barg) maximum working pressure, 500 psig (3450 kPa/35 barg) static test pressure
Resources:
- A-421 & A-423: 4-1/2" A421, 5-1/4" A-423 Super Centurion w/Two Hose Nozzles & One Pumper Nozzle 1997 Style (FH-84)
- A-420/422 2-way 1997 style w/MJ connection (Drawing #FH-166C)
- A-421/423 3-way w/MJ connection and Storz nozzle (Drawing #FH-133E)
- A-422: 4-1/2" Centurion w/2 hose nozzles (Drawing #FH-132)
- A-425 2-way (2 pumper nozzles) w/MJ shoe connection and 2-Mueller Storz nozzle connections (Drawing #FH-198D)
- A-425: 2-way (2 pumper nozzles) w/MJ connection (Drawing #FH-105C)
- A-433/435: 4-1/2" & 5-1/4" Centurion w/2 hose (Drawing #FH-111)
- A433/435: UL-FM 2-way w/ MJ connection (Drawing #CE-FH-111A)
- A-443 5-1/4" w/2 hose nozzles w/hose gate valves opt 370 (Drawing #FH-129)
- A-444 5-1/4" w/2 hose and 1 pumper opt 370 hose gate valve (Drawing #FH-130)
- A-461 4-1/2" Centurion Stop-In Bonnet (Drawing #FH-157)
- A463 - 5-1/4" Centurion Stop-In Bonnet (Drawing #FH-155)
- A454 - 5-1/4" Centurion w/3 hose nozzles (Drawing #FH-448)
- A459 - 5-1/4" Centurion w/2 hose nozzles and 2 pumper (Drawing #FH-449)
- A458 - 5-1/4" Centurion w/3 hose nozzles and 1 pumper (Drawing #FH-450)
- A444 5-1/4" w/2 hose and 1 pumper (Drawing #FH-609)
- A424 - 4-1/2" Centurion w/1 pumper (Drawing #FH-8)
- A473 - 5-1/4" Centurion Modified Stop-In Bonnet (Drawing #FH-87)
- A424 w/pumper nozzle 1997 style w/MJ connection (Drawing #FH-8C)
